3 Series Heavy Duty Utility
3 Series HD Utility Specifications
|
Travel
|
DIM "AA"
|
Bulkhead End
|
Clamp End
|
Operating Loads
|
| Inch / (mm) |
Inch / (mm) |
DIM "A"
Inch / (mm) |
DIM "B"
Inch / (mm) |
DIM "C"
Inch / (mm) |
DIM "D"
Inch / (mm)
|
Push
Lbs. / (N)
|
Pull
Lbs. / (N) |
1.0
(25.4) |
4.50
(114.3) |
3.00
(76.2) |
4.94
(125.5) |
2.31
(58.7) |
4.25
(108.0) |
60
(267) |
60
(267) |
2.0
(50.8) |
4.50
(114.3) |
4.00
(101.6) |
6.94
(176.3) |
3.31
(84.1) |
6.25
(158.8) |
60
(267) |
60
(267) |
3.0
(76.2) |
4.50
(114.3) |
5.00
(127.0) |
8.94
(227.1) |
4.31
(109.5) |
8.25
(209.6) |
60
(267)
|
60
(267) |
4.0
(101.6) |
6.50
(165.1) |
6.00
(152.4) |
10.94
(227.9) |
5.31
(134.9) |
10.25
(260.4) |
60
(267)
|
60
(267) |
5.0
(127.0) |
6.50
(165.1) |
7.00
(177.8) |
12.94
(328.7) |
6.31
(160.3) |
12.25
(311.2) |
45
(200) |
60
(267)
|
10-32 Threaded Rod - Output End
|
|
