8 Series Push-Pull Cable
8 Series Specifications | Travel | Bulkhead End | Clamp End | Operating Loads | | Inch / (mm) | DIM "A"
Inch / (mm) | DIM "B"
Inch / (mm) | DIM "C"
Inch / (mm) | DIM "D"
Inch / (mm) | Push
Lbs. / (N) | Pull
Lbs. / (N) | 1.0
(25.4) | 3.69
(93.7) | 5.56
(141.2)
| 3.19
(81.0) | 5.06
(128.5) | 700
(3114) | 1000
(4448) | 2.0
(50.8) | 4.69
(119.1) | 7.06
(179.3) | 4.19
(106.4) | 6.56
(166.6) | 700
(3114) | 1000
(4448)
| 3.0
(76.2) | 5.69
(144.5) | 8.56
(217.4) | 5.19
(131.8) | 8.06
(204.7) | 600
(2669) | 1000
(4448)
| 4.0
(101.6) | 6.69
(169.9) | 10.06
(255.5) | 6.19
(157.2) | 9.56
(242.8) | 500
(2224) | 1000
(4448)
| 5.0
(127.0) | 7.69
(195.3) | 11.56
(293.6) | 7.19
(182.6) | 11.06
(280.9) | 400
(1779) | 1000
(4448)
| 6.0
(152.4) | 8.69
(220.7) | 13.06
(331.7) | 8.19
(208.0) | 12.56
(319.0) | 275
(1223) | 1000
(4448)
| 7.0
(177.8) | 9.69
(246.1) | 14.56
(369.8) | 9.19
(233.4) | 14.06
(357.1) | 150
(667) | 1000
(4448)
| 10" Bend Radii |
|
